Bourns CRT-A Thin Film AEC-Q200 Precision Chip Resistors

Bourns CRT-A Thin Film AEC-Q200 Precision Chip Resistors are available in 0402, 0603, 0805, and 1206 package sizes that support lower tolerances from ±0.1% to ±1%. These automotive-grade resistors offer a wide temperature coefficient of resistance (TCR) ranging from ±50ppm/°C to ±10ppm/°C. The TCR range and a resistance range of 10Ω to 1MΩ are equivalent to the supported resistance range of other Bourns thick film resistors, but the CRT-A series features higher resistance tolerance accuracy compared to thick film resistors. Bourns CRT-A Thin Film AEC-Q200 Precision Chip Resistors deliver enhanced signal quality in an SMD package and are suitable for applications requiring a small package size with accurate resistance values, resistance tolerances, and TCRs. Typical applications include SD cards, DDR memory modules, mobile phones, and automotive dash cameras.
